| ब्रांड नाम: | HeJin |
| मॉडल संख्या: | HJ0608A |
| एमओक्यू: | 1 सेट |
| कीमत: | Negotiatable |
| भुगतान की शर्तें: | टी/टी, एल/सी |
| आपूर्ति करने की क्षमता: | प्रति माह 10 सेट |
The Household Appliance Power Cord Bending Tester is a precision-designed IEC testing device designed to evaluate the mechanical durability and bending resistance of power cords for household and similar appliances.
This testing system conforms to IEC 60335-1 and can simulate the repeated bending movements that occur during normal use of appliances. It provides reliable and repeatable test results for manufacturers, laboratories, certification bodies, and quality control departments.
Power cords are among the most stress-bearing components in electrical equipment. Continuous bending, pulling, and movement can lead to conductor fatigue, insulation damage, or premature product failure. This equipment accurately simulates the movement of power cords in real-world use.
IEC 60335-1
Household and Similar Electrical Appliances – Safety
Clause 25.14
Appliances provided with a supply cord and which are moved during operation shall be constructed so that the supply cord is adequately protected against excessive flexing where it enters the appliance.
The test apparatus performs the prescribed flexing test to verify compliance.
Figure 8
Specifies the construction and operating requirements of the cable flexing testing apparatus used for evaluating cord durability.
IEC 60745-1
Hand-held Motor-operated Electric Tools – Safety Requirements
Relevant cord flexing evaluation procedures.
IEC 61029-1
Transportable Motor-operated Electric Tools – Safety
Applicable for power cord endurance verification.
IEC 60335-2 Series
Specific household appliance standards requiring cord flexing assessments.
| Item Name | Parameters |
| Test station | Single station, with 1set fixture |
| Flexing angle | 45° (90°), 60° (120°), 90° (180°), and 180° (360°) left and right. Other angles from 0 to 360° can be set, and single-sided bending can be selected. |
| Flexing speed | 10~60 rpm, can be preset |
| Load weights | 5N*1,10N*1. Household Appliance Test Equipment |
| Test times | 0~999999 times, can be preset and displayed; One bend cycle is a 90° movement. |
| Starting position (origin) selection | The starting position can be set arbitrarily so that the irregular sample cord exit is perpendicular and substantially coincides with the center of rotation to minimize lateral displacement. |
| Operation principle | The servo motor drive system is adopted, high regulation precision of swing angle and speed. |
| Built-in load | The device has a built-in load 5KW voltage regulator, which can adjust the voltage from 0 to 250V and display the current and voltage digitally. |
| Power | 230V 60Hz (customizable) |
| Control | With visual touch screen display and PLC control, control and parameter settings are very intuitive and convenient. |
| Signal indication | Test completion and disconnection alarm indicator display |
Suitable products include:
Q1: Which IEC standard does this equipment comply with?
It is primarily designed according to IEC 60335-1 Figure 8 requirements.
Q2: Can the bending angle be adjusted?
Yes. Multiple flexing angles can be selected according to testing requirements.
Q3: Is the testing speed adjustable?
Yes. The speed can be adjusted within the specified range.
Q4: Can different cord sizes be tested?
Yes. The apparatus supports various household appliance power cords.
Q5: Is customization available?
Yes. HeJin offers customized solutions according to customer testing requirements.
Q6: Do you provide overseas technical support?
Yes. Remote support and complete technical documentation are available worldwide.
HeJin is a professional manufacturer focusing on:
Official Website:
https://www.autoparts-test.com/
Related Product Categories:
For more product information, technical support, or quotation requests, please contact the HeJin sales team.
