| ब्रांड नाम: | HJ |
| मॉडल संख्या: | NF-2 |
| एमओक्यू: | 1 set |
| कीमत: | Negotiatable |
| भुगतान की शर्तें: | टी/टी, एल/सी |
| आपूर्ति करने की क्षमता: | 10 set /month |
The Vertical Flame Resistance Test Device is a critical piece of Flammability Testing Equipment designed to assess the fire resistance of materials. This essential Flammability Testing Machine adheres to several industry standards including IEC60695-11-3, IEC60695-11-4, IEC60695-11-10, and IEC60695-11-20, ensuring accurate and reliable results.
Equipped with various combustion angles of 0°, 20°, and 45°, this Fire Retardant Material Test Apparatus allows for precise testing under different conditions. The capability to adjust the flame power between 50W and 500W provides flexibility in testing various materials with different flammability levels.
Operating the device is user-friendly with its PLC control system, 7-inch color touch screen interface, and included infrared remote control. This advanced control operation mode streamlines the testing process and enhances efficiency for users.
The device features a Copper Block with diameters of Ф5.5mm and Ф9mm, enabling the testing of materials of varying thicknesses and compositions. This versatility ensures comprehensive testing of a wide range of materials for their flame resistance properties.
| Power/Grade | 50W and 500W double power switching |
| Test Methods | Horizontal And Vertical Burning Test |
| Burning Times | 0-9999 times, Can be preset |
| Gas Pressure | 0.1MPa |
| Weight Of Copper Block | 1.76 G±0.01 G/10g±0.05 G |
| Flame Power | 50W&500W |
| Burning Time | 0-9999X0.1S, Can be preset |
| Test Angle | 50W: 0°,45°; 500W: 20° |
| Product Features | Simulates actual fire sources, High-precision combustion timing system, Adjustable flame height and angle, Transparent observation window, Automatic timing function |
| Copper Block | Ф5.5mm/Ф9mm |
Product Application Occasions and Scenarios for the HJ NF-2 Flammability Testing Equipment:
The HJ NF-2 Flammability Testing Equipment is a versatile tool that can be used in various industries and settings due to its reliable performance and accurate results. Here are some key application occasions and scenarios where this equipment can be effectively utilized:
1. Textile Industry: The Horizontal Flammability Testing Equipment is ideal for testing the flammability of textile materials such as fabrics and fibers. It can help textile manufacturers ensure compliance with safety regulations and standards.
2. Furniture Industry: The Vertical Flame Resistance Test Device is essential for evaluating the fire resistance of furniture materials like upholstery, padding, and coverings. This equipment can assist furniture manufacturers in producing fire-retardant products.
3. Automotive Industry: The Horizontal Vertical Burning Tester is valuable for testing the flammability of interior materials used in vehicles, such as seat covers, carpets, and dashboard components. It helps automotive manufacturers meet stringent safety requirements.
4. Research Institutions: Research institutions and laboratories can benefit from the HJ NF-2 Flammability Testing Equipment to conduct experiments and studies on the flammability properties of various materials. The equipment provides accurate data for research purposes.
5. Quality Control Departments: Businesses with quality control departments can use this equipment to assess the flammability of incoming raw materials or finished products. It ensures that only safe and compliant materials are used in production.
Overall, the HJ NF-2 Flammability Testing Equipment, with its Horizontal And Vertical Burning Test capabilities, is a valuable asset in industries where fire safety is a priority. Its precise measurements, dual power switching options, and reliable performance make it a trusted tool for flammability testing.
For more information or to place an order, please contact us. Minimum Order Quantity: 1 set. Price: Negotiable. Payment Terms: T/T, L/C. Supply Ability: 10 set/month. Delivery Time: 30 days. Packaging Details: plywood. Certification: calibration certificate (cost additional). Place of Origin: China.
Test Methods: Horizontal And Vertical Burning Test. Gas flow: 50W:105±5ml/min or 18±1mm; 500W: 965±30ml/min or 117±3 mm. Power/grade: 50W and 500W double power switching. Weight Of Copper Block: 1.76 G±0.01 G/10g±0.05 G. Flame Power: 50W&500W
Our Product Technical Support and Services for the Flammability Testing Equipment include:
- Installation guidance and assistance
- Troubleshooting support for any technical issues
- Training sessions for proper usage and maintenance
- Regular maintenance and calibration services to ensure accurate results
- Upgrades and updates to keep your equipment up-to-date with industry standards
Product Packaging and Shipping:
Our Flammability Testing Equipment is carefully packaged to ensure safe delivery to your doorstep. Each unit is securely wrapped in protective foam and placed in a sturdy cardboard box to prevent any damage during transit. Additionally, the package is labeled with clear instructions and handling guidelines.
For shipping, we partner with reliable carriers to ensure timely and efficient delivery of your order. You can track your package using the provided tracking number to stay updated on its status. Rest assured, we take every precaution to make sure your Flammability Testing Equipment reaches you in perfect condition.
Q: What is the brand name of this Flammability Testing Equipment?
A: The brand name is HJ.
Q: What is the model number of this Flammability Testing Equipment?
A: The model number is NF-2.
Q: Does this equipment come with certification?
A: Yes, it comes with a calibration certificate, which costs additional.
Q: Where is this Flammability Testing Equipment manufactured?
A: It is manufactured in China.
Q: What are the payment terms accepted for purchasing this equipment?
A: The accepted payment terms are T/T and L/C.
